Jo’s Dining Room Board and Batten

Earlier this summer I helped my sister with some painting and such, well, mostly painting.  I’ve gotten sidetracked and she’s having saw problems, so some of the project is on hold. (foyer).  However she was able to finish up her living room and dining room.  She chose two shades of green, one for the living room, the other for the dining room.  She doesn’t have a wall to separate the two rooms, so she used a faux column. I think it turned out fantastic!  The rooms look so much brighter and cheerier!

In her own words, she describes what she did:
I wanted to find a way to ‘break’ up the living and dining room with a different paint color scheme. I live in a bi-level and there is no wall between the rooms.

I decided to use a fake ‘column’ on the walls to separate the dining room from the living room and kitchen. I chose board and batten to offset the darker accent color. I had aged pine lumber available but it was unsightly. I planed it to approximately ½ inch thick by 3 ½ inches wide.

MY LATEST VIDEOS

Using a level, I used Scotch blue painter’s tape to mark a line 36”from the floor for the horizontal lines and a vertical line was marked to separate the living and dining room.

When the room started to come together, I decided to trim out the window as well. Previously, the only trim was a window sill. Using baseboard, I trimmed out three sides of the window before proceeding with the board and batten. (note the window)

The columns were placed at the newly defined lines of the dining room. The first board placed on the wall was the top horizontal board using the paint line as a reference for the center of the board. Checking for level, the board was nailed to the wall. Next was the baseboard. I chose to place a manila file folder under the baseboard. With laminate flooring, it is easier for me than trying to tape the floor when trimming. The folder leaves a small gap, but it isn’t noticeable. Next time I paint, all I have to do is put the folder under the baseboard for easier trim work.

The main focal point of the room is the window. I wanted the spacing to balance the size of the window. The window was measured and I decided that I wanted two vertical boards evenly spaced under the window. We figured out that 20 inch spacing worked out well. The first vertical boards were placed under the window. I cut scrap lumber 20 inches long and marked the center of it. I marked the center of the window ledge with painter’s tape and matched it with my scrap lumber. By placing a vertical board at each end of the horizontal scrap board, the boards would always be perfectly spaced.

I used Scotch blue tape to secure the vertical boards Once the vertical boards were taped, I continued to work along the wall.

The opposite wall had an electrical outlet. I wanted it centered in-between two vertical boards. Using my scrap lumber, I lined up the center mark of the scrap with the electrical outlet. Placing vertical boards at each end centered the outlet perfectly. Using tape to secure all of the vertical boards allows for moving boards at the end of each wall to adjust for more eye pleasing appeal.

Once everything looked the way I wanted, nails were used to secure to the wall. I didn’t use liquid nails because that would make it very difficult to remove when redecorating without destroying the plaster walls. Keeping it real: My walls were not perfect and the horizontal boards didn’t fit against the walls in all places. For those places, I used drywall screws to lessen the gap. Be sure to sink the screw heads below the surface so that caulk will hide them before touching up the paint.

All of the boards were primed and painted before attaching to the wall to minimize trim work. Once everything was nailed, it was time to caulk. I didn’t realize it would make such a HUGE difference. It filled in all of the small gaps and gave it a more custom, finished look to it. Patience is definitely required and it isn’t something you want to start unless you have the time. You don’t want to rush through it. It can make or break the entire look. Once the caulking is done, there will be some trim work, but then sit back and enjoy your accomplishment.

Didn’t it turn out fabulous?  I LOVE board and batten.  Thanks Jo for sharing this great makeover with my readers!
gail
